Description
IP / Network ● Image Sensor: 1/2.8" Progressive Scan CMOS ● Min. Illumination: 0.01Lux @ (F1.2, AGC ON), 0.01 4 Lux @(F1.4,AGC ON), 0 Lux w/ IR ● Shutter Speed: 1/3 s to 1/10,000 s ● Slow Shutter: Support ● Lens: 2.8-12 mm @ F1.4 ● Lens Mount: Φ14 ● Day/ Night: IR cut filter w/auto switch ● DNR: 3D DNR ● Wide Dynamic Range: 120dB ● Angle Adjustment: Pan:0°-355°, Tilt: 0°-75°, Rotation: 0°-355° ● Video Compression: H.264 / MJPEG/H.264 Zip+ ● H.264 Type: Main Profile ● Video Bit Rate: 32 Kbps~8 Mbps ● Audio Compression: G.711/G.722.1/G.726/MP2L2 ● Audio Bit rate: 64Kbps (G.711)/ 16Kbps(G.722.1)/ 16Kbps(G.726)/ 32-128Kbps(MP2L2) ● Max. Resolution: 1920×1080 ● Frame Rate: 60Hz: 30fps (1920×1080, 1280×960, 1280×720) ● 50Hz: 25 fps (1920×1080, 1280×960, 1280×720) ● Image Setting: Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser ● BLC: Support, zone configurable ● ROI Codec: Support ● Network Storage: NAS (Support NFS, SMB/CIFS), ANR ● Alarm Trigger: Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception ● Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour ● General: One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anon. access ● Standard: ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI ● Communication Interface: 1 RJ45 10M/100M Ethernet port ● Reset: Yes ● Working Temperature/ Humidity: -22°F~140°F (-30°C~60°C); Humidity: 95% or less (non-condensing) ● Power Supply: DC12V ± 10%, PoE (802.3af) ● Power Consumption: Max. 5.5W ● IR Range: Approx. 100' (30 meters) ● Weather Proof Ratings: IP66 ● Impact Protection: IEC6006 8-27 5Eh, 20J; EN50102, up to IK10 ● Dimensions: 5.5"×3.9" (140×99.9mm) ● Weight: 2.20lbs(1000g)
