RDL TWO-WATT UTILITY AMPLIFIER, NUMBER OF OUTPUTS: 2, FREQUENCY RESPONSE AT 600 OHM: 20 HZ-30 KHZ, FREQUENCY RESPONSE AT 8 OHM:

hello let's proceed now to calculate the frequency response of the common emitter amplifier so I have written down the DC parameters we just calculated the DC bias point as well as the mid band parameters the gain input resistance output resistance the game for the circuit was 100 that was the magnitude of the gain which is 40 DB input resistance of 10 kilo arms output resistance of 20 kilo ohms and now we're going to be calculating the values of the low and high cutoff frequencies FL and FH and we have talked about how the value of the low cutoff frequency is affected by the coupling and bypass capacitors that form high-pass filter type of responses with the resistances connected to them and the high cutoff frequency FH is affected by internal capacitances of the transistor as well as parasitic capacitances and load capacitances that form a low-pass type of response with resistance con
