Features:
Global certificates
Universal AC input / Full range
3 pole AC inlet IEC320-C14,Classy I power unit
Built-in active PFC function
No load power consumption< 0.15W
Energy efficiency Level VI
Comply with EISA 2007/DoE,NRCan,Korea K-MEPS, AU/NZ MEPS,EU ErP and CoC Version 5
Protections: Short circuit / Overload / Over voltage / Over temperature
Fully enclosed plastic case
-30~+70ºC wide range working temperature
LED indicator for power on
3 years warranty
General Specification:
AC input voltage range:90 ~264VAC 127~370VDC
AC inrush current(max.):Cold start 35A/115VAC 70A/230VAC
Current adjustment range:12V:0~6.67A, 15V:0~6A, 19V:0~4.74A, 24V:0~3.75A, 48V:0~1.87A
Over voltage protection:105 ~ 135% rated output voltage,Protection type :Shut down O/P voltage,re-power on to recover
Overload protection:110 ~ 150% rated output power,Protection type:Hiccup mode, recovers automatically after fault condition is removed
Over temperature protection:Shut down o/p voltage, re-power on to recover
Withstand voltage:I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG:0.5KVAC
Working temperature:-30~+70ºC (Refer to Derating Curve)
Safety standards:UL60950-1, CSA C22.2, TUV EN60950-1, BSMI CNS14336, CCC GB4943,PSE J60950-1,AS/NZS 60950.1, BIS IS13252,KC K60950-1,EAC TP TC 004 approved; SIRIM MS IEC60950-1 (optiona)approved
EMC standards:EN55032(CISPR32),FCC PART 15 / CISPR22 CAN ICES-3(B)/NMB-3(B),CNS13438,GB17625.1 EAC TP TC 020 MSIP KN32 Class B;EN61000-3-2 GB9254 Class A;EN61000-3-3;EN61000-4-2-3-4-5-6-8-11
Isolation resistance:I/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC/25ºC/70% RH
Dimension (LxWxH)(mm):145x 60x 32
