Mitsu. Present LAMP ReplacementFOR HC2 (VLT-HC2LP)

hi this is Steve with VFDs comm today I'm going to show you the basic wiring of a VFD since you're dealing with electricity I highly recommend that you hire an electrician to do it for you however if you choose to do it yourself make sure that you turn the power off when you're doing the wiring and use your proper safety equipment when you turn the power on now the first thing you're going to want to do is check the full load amps on the motor to make sure the PFD you bought was rate is rated for that amount of ABS also use the correct wire gauge for that amount of amps as well alright let's get started the VFD we're going to be wiring up today is the D 700 series this is the three-phase model this is a single phase model the one I'm going to be demonstrating is the single-phase model which is single-phase input three-phase output that's one of the great benefits of VFDs is that you can
