Camera
Image Sensor: 1/2.9" 6Megapixel progressive CMOS
Effective Pixels: 3072(H)x2048(V)
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3(4)~1/10000s Min. Illumination:0.01Lux/F1.4(Color), 0Lux/F1.4(IR on)
S/N Ratio: More than 50dB
Video Output: 1 port
Camera Features
Max. IR LEDs Length: 30m
Day/Night: Auto(ICR) / Color / B/W
Backlight Compensation: BLC / HLC / DWDR
White Balance: Auto/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D
Privacy Masking: Up to 4 areas
Lens
Fixed lens: 3.6mm
Max Aperture: F2.0(F2.0/F2.0)
Angle of View: H: 81°/110°/55°
Lens Type: Fixed lens
Mount Type: Board-in Type
Video
Compression: H.265;H.264;H.264H;H.264B;MJPEG
Frame Rate: Main Stream: 3M(1~20fps)/1080P/720P(1 ~ 25/30fps); Sub Stream: D1/CIF(1 ~ 25/30fps)
Bit Rate: H.265: 32K ~ 4156Kbps
Audio
Audio input: 1 CH, RCA audio input
Audio output: 1 CH, RCA audio output
Compression: G.711a; G.711Mu; AAC
Alarm
Alarm input: 1CH
Alarm output: 1 CH
Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour Compatibility: ONVIF,PSIA,CGI
Max. User Access :20users
Smart Phone: iPhone, iPad, Android
Auxiliary Interface
Memory Slot: Memory Slot : Micro SD Max 128GB
RS485: N/A
Alarm: N/A
PIR Sensor Range: N/A
General
Power Supply: DC12V, PoE (802.3af)
Power Consumption:Max 5.4W
Ingress Protection: IP67
Vandal Resistance: IK10
Dimensions: Φ122mm×89mm
Weight: 0.41kg
