now the next type of cap is ceramic now that this so tiny I'm not even going to show you but the move to ceramics is almost completely the advances in ceramic technology over the years is just amazing this keeps getting better they use they're probably the most popular capacitor by far on the planet and they use for all sorts of things now when talking about ceramic capacitors there are two basic classes defined by the EIA class 1 and class 2 class 1 ceramic capacitors are the NPO and CAG types they do come in other types but they're the two main ones and the advantage of class 1 ceramic caps is that they do not change with temperature they're very very stable but they only come in low values that's a major disadvantage now the second type is class 2 tire capacitors and there's more varieties that you can poke a damn sticker but some of the more common ones you'll hear terms like X 7 or
