Description
Image Sensor: | 1/3" Progressive Scan CMOS Min. Illumination: | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR Shutter time: | 1/3 s to 1/10,000 s Lens: | 2.8mm @ F2.0 Lens Mount: | M12 Adjustment Range: | Pan:0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360° Day& Night: | IR cut filter with auto switch Wide Dynamic Range: | 120 dB Digital noise reduction: | 3D DNR Compression Standard Video Compression: | H.264/MJPEG/H.264+ H.264 code profile: | Main Profile Video bit rate: | 32Kbps~16Mbps Dual Stream: | Yes Image Max. Image Resolution: | 2688 × 1520 Frame Rate: | 50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720) Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser BLC: | Yes, zone configurable ROI: | Support Network Network Storage: | NAS (Support NFS,SMB/CIFS), ANR Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception Protocols: | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour Security: | Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access System Compatibility: | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI Interface Communication Interface: | 1 RJ45 10M / 100M Ethernet interface General Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) Power Supply: | 12 VDC ± 10%, PoE (802.3af) Power Consumption: | Max. 5.5W (Max. 7.5W with ICR on) Weather Proof: | IP66 IR Range: | Up to 30m Dimensions: | Φ127×97.5 (5.0" × 3.8") Weight: | 670g (1.5 lbs)
