Description
Camera
Image Sensor: 1/3" CMOS sensor
Effective Pixels: 2560x1440
Min. Illumination:Color: 0.005Lux/F1.6,AGC ON, B/W 0.001Lux/F1.6,AGC ON, 0Lux with IR
Smart IR, Distance 20m
Focal Length:2.8 to 12mm, 4X Optical Zoom
Day/Night: ICR, Support AGC,HLC
Image Adjust: Sharpness, Saturation, Brightness & Contrast Adjustable ;white balance
WDR: 120dB
Shutter Speed:1/1S ~1/30,000s;
Audio
Audio: Yes, Built-in microphone + 1CH audio I/O port
Video
Video: H.265+/H.265/H.264+/H.264
Bit rate:32Kbps-16384Kbps
Pan/Tilt
Pan/Tilt Range&Speed:Pan: 0°-355°,0.1°-100°/s ; Tilt: 0°-90°,0.1°-100°/s
Network
Ethernet: 10/100Mbps, RJ45
API: ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
User Access: Supports 20 channels simultaneous live view
Client: iVMS-4200, Hik-Central, Hik-Connect
Web Browser: IE 8 to 11,Chrome 31.0+, Firefox 30.0+, Edge 16.16299+
Smart Features
Motion Detection, Video Tampering Detection, Exception, Face detection, intrusion detection, line crossing detection, region entrance detection, region exiting detection, object removal detection, unattended baggage detection, audio exception detection, ANR (Automatic Network Replenishment), dual-VCA
Certifications
Language: Support 32 languages
TF Card Slot: Support up to 256GB TF card(Not include)
Working Temperature & Humidity: -20°C to 60°C (-4°F to 140°F)/ ≤90%
Protection Level: IP66 standard, IK10, surge protection, ±2kV Line to Gnd, ±1kV Line to Line, IEC61000- 4-5
Power: DC12V/Max.9.9W or POE 802.3af/Max.11.2W; Item not included the power adapter
Dimensions: Φ130.7×101.7mm (Φ5.15"×4"inch)
Weight: 0.53kg (1.17lb)
