Image Sensor: 1/2.7'' CMOS HM2131
Pixel Size: 3μm x 3μm
Resolution: 2 MP FULL HD 1920(H) X 1080(V)
Shutter Type: Electronic rolling shutter
Focus: Manually adjustable
Focusing Range: 20mm to Infinity
Protocol & Connection: Plug-&-Play (UVC compliant)
Frame Rate:
320X240 QVGA MJPEG @120fps, 640X480 VGA MJPEG @120fps, 800X600 SVGA MJPEG @60fps, 1024X768 XGA MJPEG @30fps, 1280X720 HD MJPEG @60fps, 1280X1024 SXGA MJPEG @30fps, 1920X1080 FHD MJPEG @30fps
320X240 QVGA YUV2 @30fps, 640X480 VGA YUV2 @30fps, 800X600 SVGA YUV2 @20fps, 1024X768 XGA YUV2 @6fps, 1280X720 HD YUV2 @9fps, 1280X1024 SXGA YUV2 @6fps, 1920X1080 FHD YUV2 @6fps
Minimum Illumination: Ultra Low Light 0.001Lux
Lens: Star light 4mm lens F1.4 for 90 degree FOV with IR-Cut Filter (IR Filter) default at 650nm, custom options at 850nm or 940nm
Night vision: No IR night vision, if needed, please contact us for a different IR lens and IR illumination options.
Controllable Features: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Contrast, Exposure.
Power Socket: 4P PH 2.0mm socket, USB BUS Power.
Cable Length: Default 4ft (1.2M) (optional 2M or others upon request).
Supported OS: Win XP/Vista/Win7/Win8/Win10, Linux with UVC (linux-2.6.26 or later), MAC-OS X 10.4.8 or later, Wince with UVC, Android 4.0 or higher with UVC.
Power Consumption: DC5V (±5%), 150~200mA.
Operating Temp.: -4°F~167°F (-20°C~+75°C).
Storage Temp.: -40°F~185°F (-40°C~+125°C)
Dimension: 38mmx 38mm (Mount compatible with 32 x 32mm)
Weight: 12g (0.4OZ)
