Image Sensor: 1/4" CMOS
Pixels: 5 Mega Pixels
Image Resolution: 2592x1944 (Default), 2048x1536, 1920x1080, 1600x1200, 1280x960, 1024x768, 800x600, VGA, QVGA, 160x120
Image Compression: JPEG
Serial Interface output: TTL
Baud Rate: 9600bps, 38400bps, 57600bps, 128,000bps, 256,000bps, 460,800bps, 576,000bps, 691,200bps, and 921,600bps optional
Focal Length: 3.6mm (Default) (custom options: 2.8mm/3.6mm/8.0mm/12mm/16mm/24mm)
Angle of View (FOV): 60° (Default) (custom order options: 120°/90°/45°/30°/15°/8°)
Power Supply: DC 5V(Default), custom option 12V DC or wide voltage 9-36V DC
Current consumption: Typical: 180mA, Max: 250mA (when IR LED's are on).
Cable Length: 20CM (Default).
Infrared LED's: NO (available for custom orders).
Night image: black and white.
Night vision range: 10 meters (33ft).
IR-Cut filter: Default at 650nm, custom options at 850nm or 940nm.
IR-Cut filter switcher (ICR): Default not available, only available when customized with Spinel supplied IR illuminator.
White Balance: Automatic
Exposure: Automatic
Auto Gain Control: Automatic
Operating Temperature: -4℉-140℉
Storage Temperature: -22℉-158℉
Protocol: compatible with VC0706
Dimension: 32 x 32 x 28mm
Weight: 15g (0.5 OZ)
Connector: Default 4 bare wires.
