Quick tips:

1. Please plug the power cord into the amp THEN the wall, plug the audio cables into amp THEN switch on.

Some customers may see some slight sparks flying when they plug the power supply into the amplifier, because they use it in wrong way, you need to connect the amp to the power supply first, then plug the power supply into the 110v AC outlet, don't worry about the sparks, because this is class d amplifier, the capacitors need to charge when the power in, it's normal and safe.

Parameter:

1. Power supply range: 12v-24v;

2. THD: ≤ 0.04%;

3. Frequency Range: 20Hz - 120Hz (±1 dB);

4. SNR: ≥ 98dB;

5. Input sensitivity: ≤ 280mV;

6. Terminating impedance: 2Ohm - 8Ohm;

7. Output power: 100W for Subwoofer;

8. Input mode: 3.5mm audio input;

9. Power supply: 19V 4.74A 90W;

10. Supplied Accessories: Amplifier, Power supply, AC power cord, Manual.
