Description
Camera
Image Sensor: 1/3" Progressive Scan CMOS
Min. Illumination: Color: 0.028 lux @ (ƒ/2.0, AGC on); B/W: 0 lux with IR
Shutter time: 1/3 s to 1/10,000 s
Lens: 2.8 mm, 4 mm
Lens Mount: M12
Day& Night: IR cut filter with auto switch
Compression Standard
Video Compression: H.265, H.265+, H.264+, H.264
Video bit rate: 32Kbps~16Mbps
Audio Compression: G.711/G.722.1/G.726/MP2L2
Max. Image Resolution: 2560×1920
Frame Rate: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720)
Network
Network Storage: NAS (Support NFS,SMB/CIFS), ANR
Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP,802.1X, QoS, IPv6, Bonjour
Security: User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask
System Compatibility: ONVIF, PSIA, CGI, ISAPI
Interface
Audio Input: 1channel (2.0 ~ 2.4Vp-p, 1KOhm)
Audio Output: 1 channel (Line level, 600Ohm)
Communication Interface:
1 RJ45 10M / 100M Ethernet interface
Alarm: 1x alarm I/O On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
Operating Conditions: -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply: 12 VDC 10%, PoE (802.3af)
Power Consumption: Maximum 5 W
Impact Protection: IK10
Weather Proof: IP67
IR Range: 30 meters
Dimensions: Φ111 mm × 82 mm (4.4" × 3.2")
Weight: 500 g (1.1 lbs)
