Micron B100LP7JK Control Transformer, 100VA, 1Ph, 120 X 240Pri - 24Sec, Open Type

[Music] 97 t-series industrial control transformers by square d schneider electric such as the two shown here come supplied with two metal jumpers to Commission them for various available voltages the jumpers are supplied only for the voltage codes that require them the smaller jumpers are supplied for transformers with smaller screw terminals 150 VA and below the larger jumpers are supplied for transformers over 150 VA with larger screw terminals the jumpers are spaced exactly for use on the terminals associated with the Transformers they're shipped with these transformers have a common B one voltage code I'm wiring this one for a 240 volt input which requires a jumper on each left and right pair of screw terminals I attach my 2 240 volt incoming wires to the outer screws to complete my 240 volt primary winding when 240 volts comes in across the primary across these red wires 120 volts
