by this is a hobbyist blog a log of electronics hobbyist activities aimed at city dwellers to have limited space limited money and limited time my name is Neil welcome during this video we will continue work on the AC power component and install an illuminated power switch and some of the associated wiring looking at the AC power component circuit diagram we have the AC power input module consisting of input three-pronged socket and a half amp fuse the AC power cord has on one hand a standard three prong plug and on the other end a socket that fits into the AC power input module I'm now going to add a single pole single throw illuminated switch the black hot line is being switched when the switch is closed current flows through a neon lamp into a current limiting resistor and through the neutral line drawn in this diagram is gray the green input ground will be connected to the enclosure
