Description
Camera
Image Sensor: | 1/3" Progressive Scan CMOS
Min. Illumination: | Color: 0.028 lux @ (ƒ/2.0, AGC on); B/W: 0 lux with IR
Shutter time: | 1/3 s to 1/10,000 s
Lens: | 2.8 mm, 4 mm options; angle of view: 106° (2.8 mm), 83° (4 mm)
Lens Mount: | M12
Day& Night: | IR cut filter with auto switch
Compression Standard
Video Compression: | H.264/MJPEG/H.264+
Video bit rate: | 32Kbps~16Mbps
Audio Compression: | G.711/G.722.1/G.726/MP2L2
Max. Image Resolution: | 2560×1920
Frame Rate: |20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720)
Network
Network Storage: | NAS (Support NFS,SMB/CIFS), ANR
Protocols: | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP,802.1X, QoS, IPv6, Bonjour
Security: | User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask
System Compatibility: | ONVIF, PSIA, CGI, ISAPI
Interface
Audio Input: | 1channel (2.0 ~ 2.4Vp-p, 1KOhm)
Audio Output: | 1 channel (Line level, 600Ohm)
Communication Interface: |
1 RJ45 10M / 100M Ethernet interface
Alarm: | 1x alarm I/O On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply: | 12 VDC ± 10%, PoE (802.3af)
Power Consumption: | Maximum 5 W
Impact Protection: | IK10
Weather Proof: | IP67
IR Range: | 30 meters
Dimensions: | Φ111 mm × 82 mm (4.4" × 3.2")
Weight: | 500 g (1.1 lbs)
