Description
Camera
Image Sensor:1/1.8" Progressive Scan CMOS
Signal System:PAL/NTSC
Min. Illumination:0.0014 Lux @ (F1.0, AGC ON), 0 Lux with Light
Shutter time:1/3 s to 1/100,000 s
Slow shutter:Support
Lens:4 mm, horizontal FOV: 94°, vertical FOV: 48°, diagonal FOV: 115°
Lens Mount:M16
Adjustment Range:Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Day& Night:Auto
Wide Dynamic Range:120 dB
Digital noise reduction:3D DNR
Focus:Fixed
Compression Standard
Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate:32Kbps~16Mbps
Max. Image Resolution:1920 x 1080
Frame Rate:50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream:50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream:50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fp s(1280 × 720, 640 × 360, 352 × 240)
Image Enhancement:BLC/3D DNR/HLC/ROI
Image Settings:Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
ROI:Support 1 fixed region for main stream and sub-stream separately
Day/Night Switch:Day/Night/
Network
Network Storage:microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Protocols:TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function:One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
System Compatibility:ONVIF (Profile S, Profile G),ISAPI
Interface
Audio:1 audio input (built-in mic), mono sound(-U)
Communication Interface:1 RJ45 10M / 100M Etherne
