Aiphone - LT1 - Matching Transformer 20 To 8 Ohm

I need to attend see where locksmith bucks coming soon subscribe baby stops the upper transformer is mounted directly to the speaker assembly which is a common arrangement in antique radios today output transformers are still used but they're usually mounted to the amplifier not the speaker looking at a close-up of the schematic the transformer is represented here and the speaker here I told you earlier that this speaker requires higher wattage not high voltage this is because a speaker has low resistance but requires high current high voltage is not required to push through the low resistance coil but high current is required to get the voice coil to move I'll explain more about how the voice coil and speaker work in the next section unlike the speaker tube circuits have high resistance which require high voltage but past little current the job of the output transformer is to transform
