Digital Push Button (Yellow)/Easy To 'Plug And Play'/Large Button Keypad And First-Class Hat/Able To Achieve Very Interesting And An Interactive Work

this video describes how to use the push button in the 1 to 3d circuits simulator here we have a battery it's directly connected to a light bulb with a couple wires if we wanted to control the battery with a push button we could do that let's take a look at some example circuits here we have a push button in the circuit if I click on it the light bulb lights up and when I let go of it the light bulb goes out and that's because the push button is being used to complete the circuit it is essentially becoming the wire that's crossing between these terminals now let's look at the names of these terminals here's terminal 1 1 terminal 2 1 there's terminal 1 2 and terminal 2 - I also call these sometimes left and right and what happens is when you push the button the left side and the right side connect to each other on the inside so as long as you have one on the left and one on the right the
