ECO LLC 400KHz 3 Axis Mach3 USB Driver Motion Control Card CNC Interface Breakout Board

in this video I'm going to demonstrate how to connect the Mach 3 USB control card to all of the systems on a CNC machine or in a CNC router in this case I'm gonna demonstrate this on a machine that I'm currently working on it's an 8 foot gantry that's gonna be for an 8 by 17 machine and I'm going to demonstrate the controller connecting to two motors on the x-axis but this can also be shown for only connecting one motor on the axis on the x axis I'm going to show it as not connected as a slave so you can save one of the X's on the controller card I'm going to connect it to a smaller motor on the Y on the z-axis which is a NEMA 24 on the y-axis it's a NEMA 34 so it's kind of a medium sized motor for CNC machines or CNC routers on the x axis of the beam Neama 42 motors so those are going to be rather large and it really doesn't matter the size of the motor or the controller card really is
