HIGH-PERFORMANCE INTERNET ACCESS AND WIRELESS
The CGNM-2250 delivers speeds of up to 960Mbps with twenty-four bonded downstream channels over its DOCSIS interface. The integrated four port Gigabit Ethernet switch and Wi-Fi 3x3 802.11n+802.11ac dual band MIMO Access Point enable fast and easy home entertainment networking.
FULL DUAL STACK IPV4 / IPV6 SUPPORT
The CGNM-2250 supports full IPv4 routing features, as well as, full support for IPv6 routing and firewall. The CGNM-2250 supports both DSLite as well as 6RD for dfferent IPv6 deployment and transition strategies.
SIMPLY SECURE WIRELESS NETWORKING
The CGNM-2250 supports pre-configured and pre-enabled Wi-Fi security via Wi-Fi Protected Setup (WPS), allowing the end-user to rapidly set up a secure wireless network without manual configuration.
Protocol Support
- DOCSIS/EuroDOCSIS 1.1/2.0/3.0
- SNMP v1, v2C, v3
- IGMP TR-69
- HNAP
Interface
- RF F-type female 75Ω connector
- 4x RJ-45 Ethernet port 10/100/1000 Mbps
- 2xUSB 2.0 Type A connector with Host interface
- Wireless 802.11 a/b/g/n/ac 3T3R 2.4GHz (2412MHz~2462MHz) 11n+5GHz (5180MHz~5240MHz) 11ac dual band with 450Mbps+1300Mbps PHY data rate
Mechanical
- 8 status LEDs (Power, DS, US, Status, ETH , Wi-Fi 2.4G, Wi-Fi 5GHz, USB)
- WPS button
- Factory default reset button
- Dimensions: 177mm (W) x 204mm (H) x 45mm (D)
- Weight: 600g ± 10g
