M-7019R: 8 Channel Universal Voltage & Current Input Data Acquisition Current Module with High Voltage Protection

hi I'm Ben Adams I'm going to show you basic data acquisition using LabVIEW this video tutorials for any 4031 students here at the University of Minnesota prerequisites for this video tutorial that you have LabVIEW 2010 cell in your computer and we use a USB 6009 to acquire my voltage values you need the appropriate DMX drivers installed and I'm used a 10k potentiometer to simulate voltage values first so I'm going to show the difference between differential single-ended measurements then do a very simple data acquisition using LabVIEW then introduce the waveform data type which accumulates voltage values with time using loops and shift registers eventually writing that data to a file the DEQ is capable of making both differential and single of the measurements differential measurements are represented by the sticker on top single-ended by the stick on the bottom you pick which ones you
