Package include

1 x RTM200 USB Motion Controller

User manual and plug file send by email.

1.1 Products Introduction

     RTM200 support Mach3 software and serial port MPG, through USB to communicate with computer.

    RTM200 motion controller adopts the ARM design framework. The ARM design includes communication,codeanalytic, underlying algorithm and pulse gerneration. Rational design, reliablecontrol, convenient operation.

    This manual introduces operation, connection and usage schedule of our professional motion controller for engraving machine.

1.2 Products Features

1) Support USB,replaces the LPT port;

2) Controls upto 6-Axis simulteneously;

3) Works with Mach3 software via plugin;

4) Upto 200Khz;

5) USB connection to the control PC;

6)   Fast communication with data buffer for robust and stabile operation.

7) 5 ports input interface for ordinary digital data;

8) 3 ports output interface for ordinary digital data;

9) 1 port 0-10V spindle speed analog output interface(can change to PWM output);

10) Support 4 axis stepper systems,200KHz pulse output for every axis;

11) ARM motion control chip;

12) Compatible with MPG input(Note: this MPG input can only support the digital display MPG from our company, other brand's MPG not supported).
