Wet Sounds ST-ADP-RND 2.0 2" Stealth Clamp - Round

the fourth type of clamps used with fixtures and jigs are cam action clamps these clamps do not apply heavy clamping force so they are used with the machining operations where small vibrations are produced or in other words they are used for light to medium duty machining operations there are three basic cam types used for clamping mechanisms we have a centric action clamps we have flat spiral and we have cylindrical first we will see eccentric cams these cams apply the clamping force with the action of an eccentric circle so you can see there is a hole that is not made at the center of this scam so we are having this eccentric circle and these cams have only one true locking point so that is very important so that locking point is the point at which the vertical center line of the centric mounting hole and the lobe are perfectly aligned and exactly perpendicular to the clamping surface
