all right so this is everything hooked up uh that shows an example of switches and these are my switches over here so these would be like door sensor switches switches that go into the door that depress when the door is closed and open up when the door is open um so this is the here's a complete working setup of everything from a high level everything hooked up together so let's start with the power supply so this is an ac an ac adapter going to dc power 12 volt dc power so 12 volt dc power is coming into here and then here i have a splitter for negative and positive so the red positive is going to the red terminal here the red terminal there and then i have a comb wire comb on attached to all those terminals on that side and then that just means the power is coming in between these pairs and these pairs and those pairs are hooked up so the red wire is going to two switches so here i ha
