FIRE-LITE ALARMS H355 Addressable Heat

[Music] today at firelight we're going to review how to properly install and program in an a and nad annunciator on an intelligent addressable fire panel we'll be using the MS 9,200 UDL s as our target panel after properly wiring and installing the a nnat the display on the screen for the annunciator should indicate a key bus trouble you should also get a trouble reminder from the piezo on the annunciator that it has yet to be programmed into the system now to program the annunciator into the system we're going to press the Enter key we're going to select programming mode and our password is the default five zeros once we're into programming we're going to arrow down until we find option modules select number three we're going to select annunciators we're go into and bus options now the MS 9200 UDL s has a primary and secondary and bus allowing you to connect up to sixteen annunciators
