Linear Corp ACP00920 interface circuit board for a1

[Music] what's going on everybody it's Mike with axe you onyx and today we're going to be having a look at our la seaboard as you can see comes in a static tag now the board is out of the bag the next thing you should do is go to our website download the datasheet pour yourself a hot drink and read it I'll show you where to find the datasheet so to get to the datasheet you're going to go to our website at action XCOM and just type la si into the search box and the linear shows up right there click on that and then into technical specs from here you can download the datasheet the USB configuration instructions and the sample LabVIEW program ok now you've had to read through the datasheet it's time to look at how to set up our board the first thing to mention is the LHC board is only compatible with our P series actuators it will not work with S or R series actuators it will work with lar
