LINEAR SSW-FX Flush Mount Vandel Res 26bit Keypad

this video will show you how to install the swp to switch plate in a tabletop mark the two whole centers at forty three millimeters or one and eleven sixteenth of an inch apart first drill a hole of forty seven point one millimeters or 1 and 7/8 of an inch for the microphone drill a second hole of twenty five point two millimeters or one inch for the TS zero zero four feed the rj45 cable of the touch switch through the one-inch hole and set the SW p2 over the two holes so it is flat on the table next feed the cables from the flush mount retract a microphone through the hole of the SW p2 and sit the microphone in the switch plate so it is flush with the top of the plate make sure the microphone faces the participant after that slide the supplied oversized washer and the brass nut over the cables and onto the microphone body using your hands screw the brass nut to the top to secure the sw
