Description
[Sensing head size] M18
[Type] Unshielded
[Sensing method] Inductive type
[Sensing distance] 10 mm-10% to +10%
[Setting distance] 0 to 8 mm
[Differential distance] 10% Max. of sensing distance
[Sensing object] Ferrous metal (Sensitivity lowers with non-ferrous metals.)
[Standard sensing object] Iron 30 x 30 x 1 mm
[Power supply voltage] 24 to 240 VAC
[Operating voltage range] 20 to 264VAC
[Leakage current] 1.7 mA max.
[Control output]
Output type: AC 2-wire models
Switching capacity: 5 to 300 mA
[Indicator] Operation indicator (red)
[Operation mode] NO
[Protective circuit] Surge suppressor
[Standard or Different frequency] Standard
[Degree of protection]
IEC60529: IP67
Company standard: Oil-proof
[Connection method] Pre-wired models(Cable length: 2 m)
[Weight (Packed state)] approx. 130 g
(1)
[Type] Unshielded
[Sensing method] Inductive type
[Sensing distance] 10 mm-10% to +10%
[Setting distance] 0 to 8 mm
[Differential distance] 10% Max. of sensing distance
[Sensing object] Ferrous metal (Sensitivity lowers with non-ferrous metals.)
[Standard sensing object] Iron 30 x 30 x 1 mm
[Power supply voltage] 24 to 240 VAC
[Operating voltage range] 20 to 264VAC
[Leakage current] 1.7 mA max.
[Control output]
Output type: AC 2-wire models
Switching capacity: 5 to 300 mA
[Indicator] Operation indicator (red)
[Operation mode] NO
[Protective circuit] Surge suppressor
[Standard or Different frequency] Standard
[Degree of protection]
IEC60529: IP67
Company standard: Oil-proof
[Connection method] Pre-wired models(Cable length: 2 m)
[Weight (Packed state)] approx. 130 g
(1)
OMRON E2E-X10MY1 2M Standard Proximity Sensor (M18 Sensing Distance 10mm)(AC 2 Wire Model)(Operation Mode NO) NN
Current Price
$121.31
Average
$120.43
Min Price
$114.65
Max Price
$124.93
Price dynamics
1%
Description
[Sensing head size] M18
[Type] Unshielded
[Sensing method] Inductive type
[Sensing distance] 10 mm-10% to +10%
[Setting distance] 0 to 8 mm
[Differential distance] 10% Max. of sensing distance
[Sensing object] Ferrous metal (Sensitivity lowers with non-ferrous metals.)
[Standard sensing object] Iron 30 x 30 x 1 mm
[Power supply voltage] 24 to 240 VAC
[Operating voltage range] 20 to 264VAC
[Leakage current] 1.7 mA max.
[Control output]
Output type: AC 2-wire models
Switching capacity: 5 to 300 mA
[Indicator] Operation indicator (red)
[Operation mode] NO
[Protective circuit] Surge suppressor
[Standard or Different frequency] Standard
[Degree of protection]
IEC60529: IP67
Company standard: Oil-proof
[Connection method] Pre-wired models(Cable length: 2 m)
[Weight (Packed state)] approx. 130 g
(1)
[Type] Unshielded
[Sensing method] Inductive type
[Sensing distance] 10 mm-10% to +10%
[Setting distance] 0 to 8 mm
[Differential distance] 10% Max. of sensing distance
[Sensing object] Ferrous metal (Sensitivity lowers with non-ferrous metals.)
[Standard sensing object] Iron 30 x 30 x 1 mm
[Power supply voltage] 24 to 240 VAC
[Operating voltage range] 20 to 264VAC
[Leakage current] 1.7 mA max.
[Control output]
Output type: AC 2-wire models
Switching capacity: 5 to 300 mA
[Indicator] Operation indicator (red)
[Operation mode] NO
[Protective circuit] Surge suppressor
[Standard or Different frequency] Standard
[Degree of protection]
IEC60529: IP67
Company standard: Oil-proof
[Connection method] Pre-wired models(Cable length: 2 m)
[Weight (Packed state)] approx. 130 g
(1)
