Description
[Luminous method] Modulated
[Sensing method] Through-beam type
[Sensing distance] 0 to 1 m
[Operation mode] Light-ON
[Standard sensing object] 5 mm dia. min.: Opaque
[Directional angle] 5 to 20 deg.
[Light source] GaAs infrared LED (pulse lighting)
[Indicator] Light indicator (red)
[Power supply voltage] 5 to 24 VDC (-5% to 10%) (ripple (p-p): 5% max.)
[Current consumption] Emitter: 20 mA max.; Receiver: 20 mA max.
[Control output] Output type: NPNopen collector
Load current: 100 mA max.
Residual voltage: 0.8 V max. (at 100 mA load current)
0.4 V max. (at 10 mA load current)
[Response frequency elements] 100 Hz min.
(See "Measurement condition of Response frequency elements")
[Illumination on the surface receiver] 3000 lx max. (incandescent light)
[Ambient temperature] Operating: -10 to +55 CEL
Storage: -25 to +65 CEL(with no icing or condensation)
[Ambient humidity] Operating: 5 to 85% RH
Storage: 5 to 95% RH(with no icing or condensation)
[Vibration resistance] 200 to 2,000 Hz(peak acceleration 100 m/s**2), 1.5 mm double amplitude for 2 h (4 min periods) each in X, Y, and Z directions
[Shock resistance] 500 m/s**2 for 3 times each in X, Y, and Z directions
[Degree of protection] IP60
[Connection method] Connector type (soldering not possible)
[Weight] Package: Approx. 8.8 g
[Material] Case: Polybutylene phthalate (PBT)
[Lens: Polycarbonate(PC)
[Accessories] EE-1006L/D Connectors with Cables,Instruction Manual
(1)
[Sensing method] Through-beam type
[Sensing distance] 0 to 1 m
[Operation mode] Light-ON
[Standard sensing object] 5 mm dia. min.: Opaque
[Directional angle] 5 to 20 deg.
[Light source] GaAs infrared LED (pulse lighting)
[Indicator] Light indicator (red)
[Power supply voltage] 5 to 24 VDC (-5% to 10%) (ripple (p-p): 5% max.)
[Current consumption] Emitter: 20 mA max.; Receiver: 20 mA max.
[Control output] Output type: NPNopen collector
Load current: 100 mA max.
Residual voltage: 0.8 V max. (at 100 mA load current)
0.4 V max. (at 10 mA load current)
[Response frequency elements] 100 Hz min.
(See "Measurement condition of Response frequency elements")
[Illumination on the surface receiver] 3000 lx max. (incandescent light)
[Ambient temperature] Operating: -10 to +55 CEL
Storage: -25 to +65 CEL(with no icing or condensation)
[Ambient humidity] Operating: 5 to 85% RH
Storage: 5 to 95% RH(with no icing or condensation)
[Vibration resistance] 200 to 2,000 Hz(peak acceleration 100 m/s**2), 1.5 mm double amplitude for 2 h (4 min periods) each in X, Y, and Z directions
[Shock resistance] 500 m/s**2 for 3 times each in X, Y, and Z directions
[Degree of protection] IP60
[Connection method] Connector type (soldering not possible)
[Weight] Package: Approx. 8.8 g
[Material] Case: Polybutylene phthalate (PBT)
[Lens: Polycarbonate(PC)
[Accessories] EE-1006L/D Connectors with Cables,Instruction Manual
(1)
OMRON EE-SPW411 Long-distance Through-beam Photomicrosensor (Sensing Distance 1m)(Modulated Light)(NPN)(Light ON) NN
Current Price
$69.32
Average
$68.6
Min Price
$63.68
Max Price
$80.03
Price dynamics
1%
Description
[Luminous method] Modulated
[Sensing method] Through-beam type
[Sensing distance] 0 to 1 m
[Operation mode] Light-ON
[Standard sensing object] 5 mm dia. min.: Opaque
[Directional angle] 5 to 20 deg.
[Light source] GaAs infrared LED (pulse lighting)
[Indicator] Light indicator (red)
[Power supply voltage] 5 to 24 VDC (-5% to 10%) (ripple (p-p): 5% max.)
[Current consumption] Emitter: 20 mA max.; Receiver: 20 mA max.
[Control output] Output type: NPNopen collector
Load current: 100 mA max.
Residual voltage: 0.8 V max. (at 100 mA load current)
0.4 V max. (at 10 mA load current)
[Response frequency elements] 100 Hz min.
(See "Measurement condition of Response frequency elements")
[Illumination on the surface receiver] 3000 lx max. (incandescent light)
[Ambient temperature] Operating: -10 to +55 CEL
Storage: -25 to +65 CEL(with no icing or condensation)
[Ambient humidity] Operating: 5 to 85% RH
Storage: 5 to 95% RH(with no icing or condensation)
[Vibration resistance] 200 to 2,000 Hz(peak acceleration 100 m/s**2), 1.5 mm double amplitude for 2 h (4 min periods) each in X, Y, and Z directions
[Shock resistance] 500 m/s**2 for 3 times each in X, Y, and Z directions
[Degree of protection] IP60
[Connection method] Connector type (soldering not possible)
[Weight] Package: Approx. 8.8 g
[Material] Case: Polybutylene phthalate (PBT)
[Lens: Polycarbonate(PC)
[Accessories] EE-1006L/D Connectors with Cables,Instruction Manual
(1)
[Sensing method] Through-beam type
[Sensing distance] 0 to 1 m
[Operation mode] Light-ON
[Standard sensing object] 5 mm dia. min.: Opaque
[Directional angle] 5 to 20 deg.
[Light source] GaAs infrared LED (pulse lighting)
[Indicator] Light indicator (red)
[Power supply voltage] 5 to 24 VDC (-5% to 10%) (ripple (p-p): 5% max.)
[Current consumption] Emitter: 20 mA max.; Receiver: 20 mA max.
[Control output] Output type: NPNopen collector
Load current: 100 mA max.
Residual voltage: 0.8 V max. (at 100 mA load current)
0.4 V max. (at 10 mA load current)
[Response frequency elements] 100 Hz min.
(See "Measurement condition of Response frequency elements")
[Illumination on the surface receiver] 3000 lx max. (incandescent light)
[Ambient temperature] Operating: -10 to +55 CEL
Storage: -25 to +65 CEL(with no icing or condensation)
[Ambient humidity] Operating: 5 to 85% RH
Storage: 5 to 95% RH(with no icing or condensation)
[Vibration resistance] 200 to 2,000 Hz(peak acceleration 100 m/s**2), 1.5 mm double amplitude for 2 h (4 min periods) each in X, Y, and Z directions
[Shock resistance] 500 m/s**2 for 3 times each in X, Y, and Z directions
[Degree of protection] IP60
[Connection method] Connector type (soldering not possible)
[Weight] Package: Approx. 8.8 g
[Material] Case: Polybutylene phthalate (PBT)
[Lens: Polycarbonate(PC)
[Accessories] EE-1006L/D Connectors with Cables,Instruction Manual
(1)
