Yale 60-7150-0005-048

[Music] hello my name is rich howard owner of architectural builder supply this video is to bring you a closer look at the yale this is their part number 60. tail piece assembly this is one that's called for inch and three-quarter door without shim kit um yeah sure so a shrimp kit is obviously going to extend the distance that the trim is going to have to travel to get to the head case of the panic device if you've got a shim kit on the inside you're building that head case off further away so anyway we'll get to the parts drawing and see if we can make a little more uh that a little bit clearer diameter of the plate just heavy on inch and a half overall looks like it's about an inch and 13 16. the connecting bar or the tail piece is .322 wide and its thickness 0.098 0.098 is the thickness of the material okay now let's switch to the screen view and take a closer look at that parts draw
