Type S BT56484-6/2 App Controlled Back Up Camera

[Music] to begin the installation of the type s app view backup camera remove your license plate and set it aside [Music] locate the reverse taillights wiring behind your reverse light you may need to remove the interior panel in order to locate you only need to attach the camera to one of the reverse lights not both if you cannot locate the taillight cables please contact the vehicle manufacturer or reference a wiring diagram for your vehicle isolate the reverse light bulb and its wiring harness [Music] now feed the backup cameras power cable to your reverse taillight this will be unique for every vehicle [Music] [Music] using the provided snap lock splice connectors connect the cameras red wire to the taillights positive wire [Music] use pliers to squeeze down the metal tab to ensure a solid connection close the snap lock splice connectors once complete [Music] next connect the camera
