Description
Specification:
1.Network interface :Dual 10/100/1000M RJ45,support switch mode
3.Protocol: ONVIF 2.4.1, RTSP, RTP
4.Ethernet test:10/100/1000MLink test; link speed test;Ethernet loop detect; Ethernet flow monitor; Link quality indicator
5.IP Setting:Manual IP/ DHCP client/ DHCP Server/Multiple DHCP detect/auto DHCP status switching
6.IPC Test:Discover, inter-subnet discover,camera list,camera snapshot for fast camera indication, real time video, camera network setting
7.Analog HD test:NTSC,PAL,HD-AHD
8.Video resolution:D1, 720P, 1080P
9.Signal level:1Vpp
10.Camera test: Real time video, PTZ control, audio test, full screen preview, digital zoom of video(8 step), save snapshot, record video(h.264), video resolution and frame rate indicator.
11.Audio Test:HD-AHD Audio
12.Coaxial control: Hikvision coaxial, PELCO-C coaxial
13.Video test;Video generator;PTZ controller and test
14.Communication protocol:Hikvision coaxial,PELCO-C coaxial, Hikvision, Pelco-D/P, Samsung,Panasonic, Lilin, Yaan...more than 30 protocols 15.Baud rate:150, 300, 600, 1200, 2400, 4800, 9600, 19200bps
16.TDR Test:
0-150m RJ45 cable test,open/short/broken wire, resolution 1m
17.POE Test;PD Test;PSE Test;Network analysis;Sniff;list sub-net,ping
18.Record playback;Local playback, snapshot and video digital zoom, video frame by frame play support
19.4.0inch TFT 800*RGB*480(WVGA) resolution, 16.7M color, back light level adjustable
Internal storage 20.8GB flash;LED torch
21.Language: Chinese,English,French,Spanish,Germany,Turkish,Russian
22.Software upgrade:Online upgrade
23.Power input:POE switch or POE injector
24.12V/2Aoutput
We have very detailed user manual,please contact us to check
