1 5MP TVI(2560x1944P 12.5FPS) test, 5MP AHD(2560x1944P 12.5FPS) test, 4MP CVI(2560x1440P 25F/30F) test, 3G-SDI/HD-SDI/EX-SDI test(1080P 25/30/50/60fps)
2 Compatible with almost all models' cameras, such as Dahua, HIKVISION, Samsung and Axis
3 PoE DC48V power output, Max power 24W,12V /2A power output/5V 2A power output, as a power bank
4 UTP cable, telephone cable's sequence and connectivity test.
5 HDMI signal output, support 1080p display image, record and snapshot
6 CVBS loop test, the tester send and receive color bar generator signal ,to check BNC cable
7 Enhanced Color bar generator, PAL/NTSC multi-system color bar video generator
8 Video level meter, peak video signal level, SYNC signal level, Color bar chroma level measurement
9 Cable tracer, find a connected cable from mess cables by tone generator
10 POE/DC12V voltage and power measurement
11 IP discovery, it can auto-scan the whole network segment IP, and auto-modify tester’s IP address
12 It supports batch editing IP address
13 IP & Analog cameras, dual window test
14 Tester, android version mobile phone and PC display at the same time by TesterPlay
15 Screen capture, you can capture screen interface in any time
16 4K video files and MKV/MP4 media files play
17 Drop-down OSD menu and self-define shortcut menu
18 Shortcut button
19 Dhcp server
20 Audio in /out, support record and save the audio
21 12V 2A power output and USB 5V power output
22 8GB SD card included
23 Lithium Ion Polymer 7.4V/5000mAh Battery, working time lasts 10 hours
