Description
This three phase electric motor 0.18 KW 3000 RPM standard motor B5 flange mounted. These three phase electric motors are designed, manufactured and tested to meet the latest European and international standards, and to give maximum operating performance and reliability.
Features
Standard three phase electric motor
0.18KW 3000 RPM
B5 flange mounted
Low noise and vibration
High quality bearings
Totally enclosed fan cooled
Cast aluminium construction
Top, left or right mount terminal box
Class F insulation
High efficiency
IP55 protection rating
Specifications
Product: Standard three-phase motor
Color: Blue
Model: YS6312-0.18KW
Voltage: 230/400 V
Current: 0.95/0.55 A
Frequency: 50 Hz
Power: 0.18 kw
Phase: 3 Phase
HP: 1/4 HP
Rated speed: 2700 rpm
Synchronous speed: 3000 rpm
Shaft diameter: 11 x 20 mm
Machine base: 63
Mount type: B5 flange mounted
Service factor: 1
Insulation class: F
Protection class: IP55
Package size: 28 x 21 x 17 cm (11.02 x 8.27 x 6.69 inch)
Gross weight: 4.97 kg (10.96 lbs)
Package contents
1 x Electric Motor
